Morini CM200EI Ticino Edition Air Pistol

Description

New to PCPs?

Weighing in at 2.17 lb., Morini’s next electronic-trigger, PCP competition-grade .177-cal pistol is about 1.25 oz. lighter than its predecessor, thanks to a redesigned barrel and compensator, along with numerous carbon-fiber components and lighter-weight electronics.

The Morini CM 200EI is outfitted with a polygonally rifled, EDM (electrical discharge machine) ventilated Lothar Walther barrel with a carbon-fiber shroud running its entire length. A shorter compensator and a carbon-fiber grip insert also help shave the grams, enhancing shooter comfort and performance. It uses one CR2-3v battery (not included), as opposed to two AA cells, as in previous models. The manufacturer reports a fresh battery will provide up to 35,000 shots.

The CM 200EI features a redesigned, carbon-fiber cocking lever, replacing the bolt action found on previous models. The two included, 200 BAR (2,900 psi) air cylinders included with the pistol now feature digital manometers and the automatic shut-off conserves battery power if the pistol is inadvertently left on without being fired. There is also a training mode for newer shooters.

Each Morini CM 200EI air pistol ships with XX Small, X Small, Small,  Medium, or Large-sized wooden Morini grips with adjustable palm shelf for a custom fit in either left- or right-handed orientation. The gun also includes a small tool kit and adjustment screwdriver, fill probe and degasser. It all ships in a hard-sided case lined with a red, plush lining molded to form-fit the pistol and all included accessories.

• Shop related categories: pellet guns, pellet pistols

Morini CM200EI Ticino Edition Air Pistol

• Available in Red or Blue
• New electronic bluetooth module with applications through smartphone
• Caliber: 4.5 mm (.177)
• Weight: 985 g
• Total Length: 400 mm
• Total Height: 150 mm
• Total Width: 50 mm
• Length of Sight Line: From 330 mm to 350 mm
• Barrel Length: 230 mm
• Type of Barrel: Lothar Walther 6 dx 450 mm
• Number of Riflings: 6 Polygon
• Functioning: Compressed Air
• Digital manometer and cylinder
• Trigger: Electronic
• Path: 0 – 1.5 mm
• Arrest Point: 0.1 – 0.03 mm
• First Stage Weight: 300 g – 700 g
• Second Stage Weight: 50 g – 300 g
• Trigger: Mounted on Micro-Roller Bearing
• Voltage: 3 V
• Battery Life: 15’000 Firings ca.
• Battery (CR2-3v) not included
• Sight: 4.0 – 4.5 – 5.0 – 5.5 – 6.0 mm
• Sight Slot: Micrometrically Adjustable
• Average Bullet Speed:  Vo = 150 m/s
• Number of Shot with 200 bar: 200
• Grips: Adjustable – Left/Right

Grip Sizes Based on Palm Width

• XXS: 2.8 – 3.11 inches (71-79mm)
• XS: 3 – 3.3 inches (76-84mm)
• Small: 3.19 – 3.5 inches (81-89mm)
• Medium: 3.39 – 3.7 inches (86-94mm)
• Large: 3.58 – 3.9 inches (91-99mm)
• XL: 3.93 – 4.13 inches (100-105mm)
• XXL > 4.13 inches (105mm)

Specifications

BrandMoriniCaliber.177 (4.5mm)Max Velocity492 fpsSuggested forCompetitionPowerplantPre-charged pneumaticLoudness2-Low-MediumWeight2.17 lbsFunctionSingle-shotMax Shots per Fill200ActionBolt-actionFixed/adj. powerFixedShroudedYesScopeableNoFront SightsPostRear SightsAdjustable for windageSafetynoneTriggerTwo-stage adjustableBarrelRifledBarrel Length9.05″Overall Length15.75″Capacity1 round(s)Body TypePistolStockHardwoodGrip SizeMediumColorRedOperating Pressure2900 PSI / 200 BARGrip OrientationRightIs Safe To Dry FireYes
